Karcher HDS 10/20-4M High Pressure Washer

0 out of 5

Uncompromising across the board, with maximum pressure and maximum flow rate, the HDS 10/20-4 M hot water high-pressure cleaner is the most powerful machine in the Kärcher middle class. An innovative eco!efficiency mode as well as a precise cleaning agent dosing unit and the optimised burner engineering reduces environmental pollution and also benefit your wallet, whereas the patented nozzle technology, ceramic piston, turbo blower as well as the excellent pump efficiency ensure the best cleaning results. The clever mobility concept makes handling the machine and its transport extremely easy. What’s more, all service and maintenance work is also simple as all components are easily accessible and operating data can be called up easily at any time.

Description

Karcher HDS 10/20-4M High Pressure Washer

  • In the eco!efficiency mode the machine operates in the most economical temperature range (60°C) – with full water flow. The burner cycles are optimised to reduce fuel consumption by 20% compared to full-load operation.
  • Highly efficient, tried-and-tested burner technology. Four-pole electric motor with three-piston axial pump. Water-cooled motor for a high level of performance and durability.
  • The large, integrated water fine filter reliably protects the high-pressure pump against small dirt particles and the integrated exhaust gas thermostat switches off the drive motor if the emission temperature exceeds 300 °C.
  • The Soft Damping System (SDS) compensates for vibration and pressure peaks in the high-pressure system.
  • Safe and ample storage for protective gear, accessories and cleaning agents, also with storage hooks for power cable and high-pressure hose.
  • “Jogger” design with large rubber-tyred wheels and steering roller and integrated tilting aid to effortlessly negotiate over obstacles such as steps and kerbs.
  • Sturdy transport eyelets for safe loading during transport.

Contents in Box

  • Karcher HDS 10/20-4M High Pressure Washer
  • Cleaning agent function, 20 + 10 l tank
  • Spray gun, EASY!Force Advanced
  • High-pressure hose, 10 m
  • Spray lance, 1050 mm
  • Power nozzle

Technical data

Current type (Ph/V/Hz) 3 / 400 / 50
Flow rate (l/h) 500 – 1000
Working pressure (bar/MPa) 30 – 200 / 3 – 20
Temperature (supply 12°C) (°C) 80 – 155
Connection load (kW) 7.8
Heating oil or gas consumption, full load (kg/h) 6.4
consumption heating oil eco!efficiency (kg/h) 5.1
Power cable (m) 5
Fuel tank (l) 25
number of simultaneous users 1 / 1
Mobility Low / Low
Weight (with accessories) (kg) 167.3
Weight incl. packaging (kg) 179.3
Dimensions (L × W × H) (mm) 1330 x 750 x 1060

1 Year Warranty
