Karcher HDS 10/20-4M High Pressure Washer
- In the eco!efficiency mode the machine operates in the most economical temperature range (60°C) – with full water flow. The burner cycles are optimised to reduce fuel consumption by 20% compared to full-load operation.
- Highly efficient, tried-and-tested burner technology. Four-pole electric motor with three-piston axial pump. Water-cooled motor for a high level of performance and durability.
- The large, integrated water fine filter reliably protects the high-pressure pump against small dirt particles and the integrated exhaust gas thermostat switches off the drive motor if the emission temperature exceeds 300 °C.
- The Soft Damping System (SDS) compensates for vibration and pressure peaks in the high-pressure system.
- Safe and ample storage for protective gear, accessories and cleaning agents, also with storage hooks for power cable and high-pressure hose.
- “Jogger” design with large rubber-tyred wheels and steering roller and integrated tilting aid to effortlessly negotiate over obstacles such as steps and kerbs.
- Sturdy transport eyelets for safe loading during transport.
Contents in Box
- Karcher HDS 10/20-4M High Pressure Washer
- Cleaning agent function, 20 + 10 l tank
- Spray gun, EASY!Force Advanced
- High-pressure hose, 10 m
- Spray lance, 1050 mm
- Power nozzle
Technical data
| Current type (Ph/V/Hz) | 3 / 400 / 50 |
| Flow rate (l/h) | 500 – 1000 |
| Working pressure (bar/MPa) | 30 – 200 / 3 – 20 |
| Temperature (supply 12°C) (°C) | 80 – 155 |
| Connection load (kW) | 7.8 |
| Heating oil or gas consumption, full load (kg/h) | 6.4 |
| consumption heating oil eco!efficiency (kg/h) | 5.1 |
| Power cable (m) | 5 |
| Fuel tank (l) | 25 |
| number of simultaneous users | 1 / 1 |
| Mobility | Low / Low |
| Weight (with accessories) (kg) | 167.3 |
| Weight incl. packaging (kg) | 179.3 |
| Dimensions (L × W × H) (mm) | 1330 x 750 x 1060 |
1 Year Warranty
