Karcher HD 10/16-4 Cage Ex High Pressure Washer

0 out of 5

Potentially explosive areas, “ATEX zones”, place particular demands on components and materials. Our HD 10/16-4 Cage Ex high-pressure cleaner meets these requirements and complies with all of the tight safety regulations with its explosion-proof design. With a working pressure of 160 bar and water flow rate of around 1,000 litres per hour, the machine is designed for a variety of cleaning tasks. Moreover, it incorporates outstanding technical innovations that make cleaning effortless and take handling to a new level with the EASY!Force high-pressure gun and EASY!Lock quick-release fasteners. While the EASY!Force high-pressure gun makes use of the recoil force of the high-pressure jet to reduce the holding force to zero, the EASY!Lock quick-release fasteners enable handling five times faster than with conventional screw connections, without losing any robustness or longevity. The HD 10/16-4 Cage Ex combines maximum safety with outstanding cleaning performance and durable technology.

Description

Karcher HD 10/16-4 Cage Ex High Pressure Washer

  • Robust tubular steel frame with an integrated crane hook providing protection for the machine against damage
  • Conductive rubber tyres. Surface temperature can always mantain under 200°C.
  • Four-pole, low-speed air-cooled electric motor. Robust brass cylinder head and ceramic piston. Reliable and durable Kärcher high-performance crankshaft pump ensures optimal pressure.
  • The fresh water filter protects the components and can be removed without tools for cleaning, also protects the pump from dry running.

Contents in Box

  • Karcher HD 10/16-4 Cage Ex High Pressure Washer
  • Spray gun, EASY!Force Ex protection
  • High-pressure hose, 10 m
  • Spray lance, 1050 mm
  • Power nozzle

Technical data

Current type (Ph/V/Hz) 3 / 400 / 50
Flow rate (l/h) 1000
Working pressure (bar/MPa) 160 / 16
Max. pressure (bar/MPa) 220 / 22
Connection load (kW) 5.5
Weight (with accessories) (kg) 122.6
Weight incl. packaging (kg) 131.2
Dimensions (L × W × H) (mm) 980 x 720 x 1100

1 Year Warranty
