Karcher HD 10/16-4 Cage Ex High Pressure Washer

0 out of 5

Potentially explosive areas, “ATEX zones”, place particular demands on components and materials. Our HD 10/16-4 Cage Ex high-pressure cleaner meets these requirements and complies with all of the tight safety regulations with its explosion-proof design. With a working pressure of 160 bar and water flow rate of around 1,000 litres per hour, the machine is designed for a variety of cleaning tasks. Moreover, it incorporates outstanding technical innovations that make cleaning effortless and take handling to a new level with the EASY!Force high-pressure gun and EASY!Lock quick-release fasteners. While the EASY!Force high-pressure gun makes use of the recoil force of the high-pressure jet to reduce the holding force to zero, the EASY!Lock quick-release fasteners enable handling five times faster than with conventional screw connections, without losing any robustness or longevity. The HD 10/16-4 Cage Ex combines maximum safety with outstanding cleaning performance and durable technology.

Description

Karcher HD 10/16-4 Cage Ex High Pressure Washer

Robust tubular steel frame with an integrated crane hook providing protection for the machine against damage
Conductive rubber tyres. Surface temperature can always mantain under 200°C.
Four-pole, low-speed air-cooled electric motor. Robust brass cylinder head and ceramic piston. Reliable and durable Kärcher high-performance crankshaft pump ensures optimal pressure.
The fresh water filter protects the components and can be removed without tools for cleaning, also protects the pump from dry running.

Contents in Box

Karcher HD 10/16-4 Cage Ex High Pressure Washer
Spray gun, EASY!Force Ex protection
High-pressure hose, 10 m
Spray lance, 1050 mm
Power nozzle

Technical data

Current type (Ph/V/Hz)	3 / 400 / 50
Flow rate (l/h)	1000
Working pressure (bar/MPa)	160 / 16
Max. pressure (bar/MPa)	220 / 22
Connection load (kW)	5.5
Weight (with accessories) (kg)	122.6
Weight incl. packaging (kg)	131.2
Dimensions (L × W × H) (mm)	980 x 720 x 1100
